CLOPAY® COMMERCIAL DOORS
VERTISTACK® CLEAR DOOR
Bring modern design and space-saving functionality together with the Clopay® VertiStack® Clear Door. Its unique sectional design stacks vertically above the opening, eliminating traditional overhead tracks and helping preserve valuable ceiling space. Full-view panels create a clean architectural appearance while allowing natural light and visibility into commercial spaces.
VERTICAL-STACKING DESIGN
CLEAR OVERHEAD SPACE
FULL-VIEW ARCHITECTURAL STYLE
MODELS & SPECIFICATIONS
CHOOSE THE RIGHT VERTISTACK® CLEAR MODEL
VertiStack® Clear is available in two commercial models with the same standard opening-size range and distinctive vertical-stacking design. Choose between the standard VS904 or the insulated VS904U configuration based on the needs of your project.
VS904
STANDARD MODEL
Full-view VertiStack® Clear configuration for commercial applications where the distinctive vertical-stacking design and modern architectural appearance are desired.
MIN. OPENING WIDTH
4'6"
MAX. OPENING WIDTH
20'0"
MIN. OPENING HEIGHT
4'0"
MAX. OPENING HEIGHT
14'0"
THICKNESS
2-1/8"
INSULATION
N/A
VS904U
INTELLICORE® INSULATED MODEL
VertiStack® Clear configuration featuring Intellicore® insulated rails and stiles for projects where an insulated frame configuration is desired.
MIN. OPENING WIDTH
4'6"
MAX. OPENING WIDTH
20'0"
MIN. OPENING HEIGHT
4'0"
MAX. OPENING HEIGHT
14'0"
THICKNESS
2-1/8"
INSULATION
Intellicore® insulated rails & stiles
OPENING & INSTALLATION INFORMATION
The door is always 6 inches wider than the opening width, resulting in a door-width range of 5'0" to 20'6". VertiStack® Clear is designed for interior-mount commercial applications.
PRODUCT OPTIONS
CUSTOMIZE YOUR VERTISTACK® CLEAR DOOR
Configure the VertiStack® Clear Door to complement your commercial space with a selection of glazing materials and aluminum frame finishes. Available options allow you to balance visibility, natural light, privacy, and architectural appearance.
GLAZING MATERIALS
Choose from a variety of glazing materials to achieve the desired combination of visibility, natural light, privacy, and appearance.
CLEAR GLASS
BRONZE TINTED GLASS
GRAY TINTED GLASS
MIRRORED GLASS
WHITE LAMINATE GLASS
FROSTED GLASS
CLEAR ACRYLIC
CLEAR POLYCARBONATE
WHITE POLYCARBONATE
ALUMINUM FINISHES
Select an aluminum finish to coordinate the door frame with the architectural style of your commercial facility.
CLEAR ANODIZED
STANDARD WHITE
STANDARD BLACK
DARK BRONZE
Additional glazing and finish options may be available. Contact South Gate Commercial Doors & Accessories for current product availability and project-specific options.
BUILT FOR PERFORMANCE
MODERN DESIGN. CLEAR OVERHEAD SPACE.
The Clopay® VertiStack® Clear Door combines a modern full-view appearance with a unique vertical-stacking design. Instead of using traditional overhead tracks, the door sections stack above the opening, helping preserve valuable ceiling space and avoid interference with mechanical, electrical, and plumbing fixtures.
Its streamlined design eliminates exposed hinges, tracks, and cables for a clean architectural appearance. A variety of aluminum finishes and glazing materials allow the door to be configured for commercial spaces where visibility, natural light, and modern design are important.
VERTICAL-STACKING SECTIONS
Sections stack above the opening to help keep overhead ceiling space clear.
OPERATION OPTIONS
Available with a motor operator or manual hand-chain operation.
CLEAN ARCHITECTURAL DESIGN
No exposed hinges, tracks, or cables create a streamlined appearance.
INTEGRATED SAFETY
A strap brake safety system is designed to engage if strap tension is lost.
INTERESTED IN THE VERTISTACK® CLEAR DOOR?
South Gate Commercial Doors & Accessories can help you determine whether the Clopay® VertiStack® Clear Door is the right solution for your commercial project. Contact our team for product information, available configurations and options, professional installation, service, and a quote.
VertiStack® Clear Door • Product Options • Professional Installation • Service & Support
